TC1 10,240
MHz Referenzfrequenz L18 10,240 MHz
L1 HF-Eingang
L2 HF-Eingang
L3 HF-Eingang
L4 HF-Eingang
L6 ZF (10,7 MHz)
L7 FM-Diskriminator (Demodulator)
VR5 Mikrofon . Verstärkung
VR6 FM-Abweichung (FM-Modulation)
L19 VCO-Spule
L20 Sender
L21 Sender
L24 Sender
L27 Sender
